Full Face Gas Mask — FFM-DS Double Seal Full Face Mask PAPR Gas System | AYO WX
Choose your system:
The system includes everything to get started, but to save the trouble of buying new filters soon, we recommend buying some packs of spare filters to suit your working conditions and frequency of use.
Includes one AYO WX HEPA Filter – Gas + one gas cartridge of your choice.
Full face protection from organic vapours and dust, with built-in eye protection
AYO WX FFM-DS Gas is a full face gas mask PAPR with a double seal, tight-fitting mask. Its Gas main unit combines an A2 gas cartridge with a HEPA particulate filter, protecting against Type A organic gases and vapours, such as solvents, with a boiling point above 65 °C, as well as airborne particulates, with eye and face protection built in.
Typical uses include fibreglass and composite work, boat building, adhesives, printing and solvent cleaning, where vapours such as styrene, toluene, n-butyl acetate and isopropyl alcohol are common.
AYO WX FFM-DS Double Seal PAPR System sets a new standard for full face powered respirators.
Australia’s workplace exposure limits for many solvents fall on 1 December 2026. See what changes in our Workplace Exposure Limits 2026 guide.
Need protection from dust and fumes only? See the AYO WX FFM-DS Double-Seal Full-Face Mask PAPR P-Boost System.
- Key Features
- Key Benefits
- Technical Specifications
- Training Videos
- User Manuals and Quick Guides
- Certifications
- A unique double seal, the first of its kind in the world, achieving an unprecedented fit factor of over 2000.
- Exceptionally clear and scratch-resistant lens with a magnificent field of view.
- Combined filtration: A2 gas cartridge + AYO WX HEPA Filter – Gas.
- No hose, no belt, easy to don and doff.
- Gas cartridge options: A2-EU (A1B1E1K1-EU coming soon).
- Up to 130 L/min peak flow with advanced breath-responsive flow control.
- Battery run time from 4 up to 9 hours.
- Filter-blocked and low-battery alarms, plus a 3-level peak flow check.
- Industry-leading built-in speech diaphragm.
- Easier to clean and maintain than traditional PAPRs.
- Offering very high protection even when the pressure inside the mask briefly falls to negative during very heavy breathing.
- Gas, particulate and eye protection in one system.
- Ensuring protection and WHS compliance economically.
Specifications may be updated as certifications and product options change.
Aimwell™ AYO WX FFM
- Full Face Mask System Donning and Doffing
- Full Face Mask
- Full Face Plug Sheath
Aimwell™ AYO WX Main Unit
- Changing Filters
- Main Unit Basic Operation
- Control Panel
- Operation Mode
- Basic Diagnostics
- Battery Charging
- Battery Replacement
- Older version (before 2025)
- New version (after 2025)
- Push-Fit & Twist-Release Connection Cleaning
- Main Unit Dust Sleeve
- Cleaning
Aimwell™ AYO TALK-MIC
AYO WX User Manuals:
AYO WX FFM Quick Guides:
AS/NZS 1716:2012 PAPR-A1P3
EN 12942:2023 TM3A2P MS
EN 12942:2023 TM3A1B1E1K1P MS (coming soon)
see more: AYO WX Certifications
Verify the Mask Size
| FFM-DS (Double Seal) | |
| Mask Size | Recommended Height |
| Medium – Large | 110-140 mm |
Note:
- User protection is compromised when tight-fitting Mask Assembly does not fit the user properly.
- Always perform the Fit Test assessment for better fit and protection for tight-fitting masks.
RELATED PRODUCTS
AYO WX HEPA Filter – Gas (Pack of 3)
$70.20
AYO WX Gas Filter Cartridge-A2-EU
$93.60
AYO WX Combined Filter Unit-A2-EU
